SOQUETES E ACESSÓRIOS
b
Torx® e Torx Plus® marcas registradas da Acument Intellectual Properties, LLC. USA (antiga Camcar Textron)
D 20
Soquete estriado 1/4”
R3
4 - 14
!
3/16”- 9/16”
"
DIN 3124, ISO 2725-1
Aço Gedore-Vanadium. Niquelado e cromado. Parede fina. Para
trabalhar com acessórios manuais com encaixe
a
6,35 mm (1/4”),
conforme DIN 3120 - C 6.3, ISO 1174. Facilita trabalhos com pe-
quenos parafusos sextavados. Modelo curto.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t1
mm
/
013.101
D 20 - 4 mm
25
6,9
12,0
2,0
9
013.102
D 20 - 4,5 mm
25
7,5
12,0
2,3
8
013.103
D 20 - 5 mm
25
8,2
12,0
2,5
11
013.104
D 20 - 5,5 mm
25
8,8
12,0
3,0
12
013.105
D 20 - 6 mm
25
9,4
12,0
3,5
10
013.106
D 20 - 7 mm
25
11,0
12,0
4,0
13
013.107
D 20 - 8 mm
25
12,0
12,0
5,0
13
013.108
D 20 - 9 mm
25
13,0
13,0
5,0
15
013.109
D 20 - 10 mm
25
14,7
14,7
6,0
20
013.110
D 20 - 11 mm
25
16,0
16,0
7,0
24
013.111
D 20 - 12 mm
25
17,0
17,0
8,0
26
013.112
D 20 - 13 mm
25
18,5
18,5
8,0
29
013.113
D 20 - 14 mm
25
19,7
19,7
10,0
36
Código
Ref.
%
L
mm
d1
mm
d2
mm
t
mm
/
013.151
D 20 - 3/16”
25
7,8
12,0
2,5
10
013.152
D 20 - 7/32”
25
8,8
12,0
3,0
11
013.153
D 20 - 1/4”
25
9,8
12,0
3,5
11
013.154
D 20 - 9/32”
25
11,0
12,0
4,0
12
013.155
D 20 - 5/16”
25
12,0
12,0
5,0
12
013.156
D 20 - 11/32”
25
13,0
13,0
5,0
15
013.157
D 20 - 3/8”
25
14,0
14,0
6,0
17
013.161
D 20 - 13/32”
25
15,0
15,0
6,0
20
013.158
D 20 - 7/16”
25
16,0
16,0
7,0
22
013.159
D 20 - 1/2”
25
18,0
18,0
8,0
28
013.160
D 20 - 9/16”
25
20,0
20,0
10,0
34
D 20 L
Soquete estriado longo 1/4”
R3
3/16”- 1/2”
"
Aço Gedore-Vanadium. Niquelado e cromado. Parede fina. Para
trabalhar com acessórios manuais com encaixe
a
6,35 mm (1/4”),
conforme DIN 3120 - C 6.3, ISO 1174. Facilita trabalhos com pe-
quenos parafusos sextavados. Modelo longo.
Código
Ref.
%
L
mm
d1
mm
d2
mm
t
mm
/
013.162
D 20 L - 3/16”
50
7,8
12,0
3,7
16
013.163
D 20 L - 7/32”
50
8,8
12,0
4,5
17
013.164
D 20 L - 1/4”
50
9,8
12,0
5,2
17
013.165
D 20 L - 9/32”
50
11,0
12,0
6,0
22
013.166
D 20 L - 5/16”
50
12,0
12,0
7,5
25
013.167
D 20 L - 11/32”
50
13,0
13,0
7,5
29
013.168
D 20 L - 3/8”
50
14,0
14,0
9,0
33
013.169
D 20 L - 7/16”
50
16,0
16,0
10,5
43
013.170
D 20 L - 1/2”
50
18,0
18,0
12,0
54
TX 20
Soquete perfil Torx® 1/4”
R9
E4 - E10
9
Aço Gedore-Vanadium. Niquelado e cromado. Parede fina. Para
trabalhar com acessórios manuais com encaixe
a
6,35 mm (1/4”),
conforme DIN 3120 - C 6.3, ISO 1174, com sistema de retenção por
esferas. Indicado para parafusos perfil Torx®. Modelo curto.
Código
Ref.
+ &
L
mm
d1
mm
d2
mm
t
mm
/
013.601
TX 20 - E4
M3 3,86 25
5,5
12
4,5
8
013.603
TX 20 - E5
M4 4,75 25
7,0
12
5,0
9
013.605
TX 20 - E6
M5 5,74 25
8,0
12
5,0
10
013.606
TX 20 - E7
M6 6,22 25
9,5
12
6,0
11
013.607
TX 20 - E8
M6-M7 7,52 25 10,5 12
6,5
14
013.609
TX 20 - E10
M8 9,42 25 13,0 13
7,0
18
VEJA TAMBÉM
jogo de soquetes 1/4” - 1/2”
ref. 19V20 U-20, na página 150
DG 20
Soquete estriado articulado 1/4”
R3
5,5 - 13
!
1/4”- 9/16”
"
Aço Gedore-Vanadium. Niquelado e cromado. Articulação (até
60º) permite a utilização em locais de difícil acesso. Para trabalhar
com acessórios manuais com encaixe
a
6,35 mm (1/4”), conforme
DIN 3120 - C 6.3, ISO 1174.
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
014.380
DG 20 - 5,5 mm
38,0
8,8
14
3,0
30
014.381
DG 20 - 6 mm
38,0
9,4
14
3,5
30
014.382
DG 20 - 7 mm
38,0
11,0
14
4,0
30
014.383
DG 20 - 8 mm
38,0
12,0
14
5,0
30
014.384
DG 20 - 9 mm
38,0
13,0
14
5,0
50
014.385
DG 20 - 10 mm
39,0
14,7
14
6,0
40
014.386
DG 20 - 11 mm
41,0
16,0
14
7,0
40
014.387
DG 20 - 12 mm
42,0
17,0
14
8,0
40
014.388
DG 20 - 13 mm
42,0
18,5
14
8,0
40
Código
Ref.
$
L
mm
d1
mm
d2
mm
t
mm
/
014.389
DG 20 - 1/4“
38,0
9,8
14
3,5
25
014.390
DG 20 - 5/16“
38,0
12,0
14
5,0
26
014.391
DG 20 - 3/8“
39,0
14,0
14
6,0
27
014.392
DG 20 - 7/16“
41,0
16,0
14
7,0
40
014.393
DG 20 - 1/2“
42,0
18,0
14
8,0
40
014.394
DG 20 - 9/16“
43,5
20,0
14
9,0
40
